7X08A05WNA Technical Specifications
Lenovo Thinksystem SR530 3106 16G
General Information
- Product Name: Thinksystem SR530 3106 16G
- Product Line: ThinkSystem
- Product Series: SR530
- Product Model: 7X08A05WNA
- Product Type: Server
Controllers
- Controller Type: 12Gb/s SAS
- RAID Supported: Yes
Display & Graphics
- Graphics Controller Manufacturer: Matrox
- Graphics Controller Model: G200
I/O Expansions
- Total Expansion Bays: 8
- Internal 2.5″ Bays: 8
- Hot Swappable Bays: Yes
Memory
- Standard Memory: 16 GB
- Memory Technology: DDR4 SDRAM
- Total Memory Slots: 12
- Occupied Memory Slots: 1
Network & Communication
- Ethernet Technology: Gigabit Ethernet
Power Description
- Input Voltage: 120 V AC, 230 V AC
- Supported Power Supplies: 2
- Installed Power Supplies: 1
- Maximum Power Supply Wattage: 750 W
Storage
- Total Hard Drive Capacity: No
Processor & Chipset
- Supported Processors: 2
- Installed Processors: 1
- Processor Manufacturer: Intel
- Processor Type: Xeon Bronze
- Processor Model: 3106
- Processor Cores: Octa-core (8 Core)
- Processor Speed: 1.70 GHz
Software
- Operating System: No
Physical Characteristics
- Form Factor: Rack
- Rack Height: 1U
- Height: 1.7″
- Width: 19″
- Depth: 30.6″
