860102-S01 Technical Specifications
HP Proliant DL160 Gen9 Smart Buy featuring 1X Intel Xeon E5-2609V4 at 1.7GHz
GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 860102-S01
Product Name: HP ProLiant DL160 Gen9 – 1U Rack-Mountable Server (Smart Buy Model)
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5-2609v4, 1.7GHz
Quickpath Interconnect: 6.4 GT/s
Number of Cores: 8 (Octa-core)
64-Bit Computing: Yes
Compatible Processor Socket: FCLGA2011-3
Installed Qty: 1 (Max Supported: 2)
Main Features: Intel Turbo Boost Technology 2
CACHE MEMORY:
Type: Smart Cache
Installed Size: 20 MB (per processor)
MEMORY:
Installed Size: 8 GB (Max: 256 GB)
Technology: DDR4 SDRAM
Speed: 1866 MHz
Form Factor: DIMM 288-Pin
Slots: 16 x DDR4 RAM Slots
Features: Registered
Configuration: 1 x 8 GB
Supported RAM: PC4-17000 – 256 GB – Registered / PC4-17000 – 512 GB – Load-Reduced
STORAGE:
Hard Drive: None
Optical Drive: None
STORAGE CONTROLLERS:
Controller Name: Smart Array H240
Disk Drive: Supports 12GB/s SAS and 6GB/s SATA
Maximum Capacity: 144TB
RAID Support: RAID 0, 1, 5, 10, 50
NETWORK & COMMUNICATION:
Networking: Integrated Network Adapter
Ethernet Ports: 2x Gigabit Ethernet
Remote Management: Integrated Lights-Out 4
POWER DESCRIPTION:
Type: Non-Hot-Plug Power Supply
Installed Qty: 1
Nominal Voltage: AC 100-240V (50/60 Hz)
Power Provided: 550 Watt.
