AP32E-US Juniper Mist WiFi 6 Access Point System
AP32E-US Overview
The Juniper AP32E-US combines advanced Mist AI technology with Wi-Fi 6 capabilities, enhancing network operations and optimizing Wi-Fi performance. It achieves an impressive aggregate data rate of up to 3.0 Gbps across both 2.4GHz and 5GHz bands, ensuring seamless connectivity for all users.
2,975.64 AED
Description
AP32E-US Technical Specifications
Juniper Mist WiFi 6 Access Points
Wi-Fi Standard
Supports 802.11ax (Wi-Fi 6) with features such as OFDMA, 1024-QAM, MU-MIMO, Target Wake Time (TWT), and Spatial Frequency Reuse (BSS Coloring), while maintaining compatibility with older standards (802.11a/b/g/n/ac).
Antenna Options
External antennas available.
Applicable Country
United States.
Combined Highest Supported Data Rates
3.0 Gbps total.
2.4 GHz
2×2:2 802.11b/g/n/ac supports data rates up to 400 Mbps; 2×2:2 802.11ax reaches up to 575 Mbps.
5 GHz
4×4:4 802.11ax can deliver up to 2,400 Mbps.
MIMO Operation
Single User (SU) MIMO enables four spatial streams for a maximum of 2,400 Mbps to individual devices, while Multi User (MU) MIMO allows simultaneous connections to up to four clients.
Dedicated Third Radio
Includes a dual-band WIDS/WIPS radio for extensive spectrum analysis and client location analytics.
Bluetooth 5.0
Features an omni-directional Bluetooth antenna supporting iBeacon and Eddy Stone in super beacon mode.
Beam Forming
Equipped with Transmit Beamforming and Maximal Ratio Combining technologies.
Power Options
Compatible with 802.3at PoE and 802.3bt PoE.
Dimensions
Measures 202 x 202 x 44 mm (7.95 x 7.95 x 1.73 in).
Operating Temperature
Functionality ranges from -20° to 50° C.
Operating Humidity
Operates effectively in environments with 10% to 90% relative humidity, non-condensing.
Operating Altitude
Supports operation at altitudes up to 3,048 m (10,000 ft).
