AP61-US Technical Specifications
Mist AP61 Wireless Access Point
Manufacturer: Juniper Mist Cloud Products
Brand: MIST
Product Line: Mist
Model: AP61
Country Kits: United States
Packaged Quantity: 1
Antenna
Antenna Form Factor: Internal
Chassis
Ruggedized Design: Outdoor
Networking
Type: Wireless Access Point
Form Factor: External
Connectivity Technology: Wireless
Data Link Protocol: IEEE 802.11g, IEEE 802.11a, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11b
Wireless Protocol: Bluetooth, 802.11a/b/g/n/ac Wave 2
Data Transfer Rate: 2.5 Gbps
Wi-Fi Bands: 2.4 GHz, 5 GHz
Power Over Ethernet (PoE): PoE
Status Indicators: Status
Features: 4×4 MU-MIMO technology, Power over Ethernet (PoE), Wireless Intrusion Prevention System (WIPS), Radio resource management (RRM), Wireless Intrusion Detection System (WIDS), Proactive Analytics and Correlation Engine (PACE), Beamforming technology
Compliant Standards: IEEE 802.11b, IEEE 802.3at, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11n, IEEE 802.11g
Interface Provided
Interfaces: 1 x 1000Base-T (PoE) – RJ-45, 1 x 1000Base-T – RJ-45
Internet of Things (IoT)
Communications Technology: Bluetooth Low Energy (LE)
Miscellaneous
Color Category: White
Compliant Standards: CAN/CSA-C22.2 No. 60950-1, FCC Part 15.247, RSS-247, FCC Part 15.109, FCC Part 15.407, FCC Part 15.107, UL 60950-1, ICES-003
Dimensions & Weight
Width: 12.2 inches
Depth: 12.2 inches
Height: 4.2 inches
Weight: 10 lbs
Environmental Parameters
Min Operating Temperature: -4 degrees Fahrenheit
Max Operating Temperature: 149 degrees Fahrenheit
Humidity Range Operating: 10 – 90% (non-condensing)
