CL8068404165100 Technical Specifications
Intel Xeon E-2276ML 6-Core Processor Overview
Brand: Intel
Part Number: CL8068404165100
Type: Embedded Processor
Series: Xeon E Processor
Core Model: E-2276ML
Code Name: Coffee Lake
Core Stepping: U0
Manufacturing Process: 14 nm
Cores: 6
Threads: 12
Base Clock Speed: 2.00 GHz
Max Turbo Frequency: 4.20 GHz
L3 Cache: 12 MB
Front Side Bus: 8.00 GT/s
Thermal Design Power: 25 Watts
Maximum Memory Capacity: 64 GB
Memory Types Supported: DDR4-2666
Memory Channels: 2
ECC Memory Support: Yes
Socket Type: BGA1440
Maximum CPU Configuration: 1
Tjunction: 100 °C
Package Dimensions: 42mm x 28mm
Integrated Graphics: Intel UHD Graphics P630
Graphics Base Frequency: 350 MHz
Maximum Dynamic Frequency: 1.15 GHz
Video Memory: 64 GB
Graphics Outputs: eDP/DP/HDMI/DVI
4K Support: Yes, at 60Hz.
