FTLX8512D3BTL Technical Specifications
10Gb/s 850nm Multimode Datacom XFP
This hot-pluggable XFP transceiver features a compact footprint and supports data rates from 8.5Gb/s to 10.5Gb/s, including 10 Gigabit Ethernet. It has a low power dissipation of less than 1.5W and operates within a temperature range of -40°C to +85°C. The device requires a single 3.3V power supply and can achieve a maximum link length of 300 meters. Utilizing an 850nm heated VCSEL laser, it is equipped with an LC Duplex connector, eliminating the need for a Reference Clock. Additionally, it includes built-in digital diagnostic functions and features a standard bail release mechanism for easy handling.
