HX-C480-M5 Technical Specifications
Cisco Systems UCS C480 M5 Base Chassis
General Information
Product Name: UCS C480 M5 Standard Base Chassis without CPU Memory
Manufacturer Part Number: HX-C480-M5
Product Series: C480 M5
Product Type: Barebone System
Interfaces/Ports
Total USB Ports: 3
USB 3.0 Ports: 3
Controllers
Controller Types: Serial SATA, 12Gb/s SAS
Display & Graphics
Graphics Memory Capacity: 256 MB
I/O Expansions
2.5″ Internal Bays: 32
Total Expansion Slots: 12
PCI Express x8 Slots: 6
PCI Express x16 Slots: 6
Memory
Maximum Memory: 6 TB
Memory Technology: DDR4 SDRAM
Memory Standard: DDR4-2933/PC4-23466
Total Memory Slots: 48 DDR4 Slots
Intel Optane Memory Ready: Yes
Network & Communication
Ethernet Technologies: 10 Gigabit Ethernet, Gigabit Ethernet
Power Description
Input Voltage: 120 V AC, 230 V AC
Maximum Power Supply Wattage: 1600 W
Processor & Chipset
Supported Processors: 4
Compatible Processors: Xeon Platinum, Gold, Silver, Bronze
64-bit Processing: Yes
Chipset Manufacturer: Intel
Chipset Model: C620
Physical Characteristics
Form Factor: Rack-mountable
Rack Height: 4U
Dimensions: Height 6.9″, Width 19″, Depth 32.7″
