HX-SP-240M5SX-V1 Technical Specifications
Cisco Systems SP HX240C HyperFlex Server
General Information
Product Name: SP HX240C HyperFlex Server 2X4114 12X32G MEM
Manufacturer Part Number: HX-SP-240M5SX-V1
Product Line: HyperFlex
Product Series: HX240c M5
Product Type: Server
Controllers
Controller Type: 12Gb/s SAS
RAID Support: No
Display & Graphics
Graphics Controller Manufacturer: ASPEED
Graphics Controller Model: Pilot 4
Graphics Memory Capacity: Up to 16 MB
I/O Expansions
Total Expansion Bays: 26
Internal 2.5″ Bays: 26
Hot Swappable Bays: Yes
Memory
Standard Memory: 384 GB
Maximum Memory: 3 TB
Memory Technology: DDR4 SDRAM
Total Memory Slots: 24 DDR4
Occupied Memory Slots: 12
Network & Communication
Ethernet Technology: 10 Gigabit Ethernet
Power Description
Supported Power Supplies: 2
Installed Power Supplies: 2
Maximum Power Supply Wattage: 1600 W
Redundant Power Supply: Yes
Storage
Total SSD Capacity: 240 GB
SSD Interface: M.2
Processor & Chipset
Supported Processors: 2
Installed Processors: 2
Processor Manufacturer: Intel
Processor Type: Xeon Silver
Processor Model: 4114
Processor Cores: Deca-core (10 Core)
Processor Speed: 2.20 GHz
Physical Characteristics
Form Factor: Rack
Rack Height: 2U
Height: 3.4″
Width: 19″
