P10947-B21 Technical Specifications
HPE Intel Xeon Gold 6230 20-Core Processor Upgrade
Brand: Intel
Part Number: P10947-B21
Processor Type: Server
Family: 2nd Generation Intel Xeon Scalable Processors
Core Model: 6230
Code Name: Cascade Lake
Stepping: B1
Manufacturing Process: 14 nm
Cores: 20
Threads: 40
Base Clock Speed: 2.10 GHz
Max Turbo Frequency: 3.90 GHz
L3 Cache: 27.5 MB
UPI Links: 3
Thermal Design Power: 125 Watts
Max Memory Capacity: 1 TB
Supported Memory Types: DDR4-2933
Max Memory Speed: 2933 MHz
Memory Channels: 6
ECC Memory: Supported
Intel Optane DC Persistent Memory: Supported
Socket Type: LGA 3647
Package Dimensions: 76.0mm x 56.5mm
TCASE: 87 °C
Embedded Options: Available
Scalability: 4S
PCI Express: 3.0
Max PCI Express Lanes: 48
Advanced Features: Enhanced Intel SpeedStep Technology, Intel 64, Intel Deep Learning Boost, Intel Hyper-Threading, Intel Resource Director Technology, Intel Turbo Boost Technology 2.0, Intel Virtualization Technology, and more.
Security Features: Execute Disable Bit, Intel AES New Instructions, Intel Trusted Execution Technology, and more.
Condition: OEM.
