UCS-CX-B200M3-P2 Technical Specifications
Cisco UCS B200 M3 Blade Server
Bay Provided
Form Factor: 2.5″ SFF
Free Qty: 2
Total Qty: 2 Bays
Cache Memory
Installed Size: 50 MB
Per Processor Size: 25 MB
Chassis
Form Factor: Blade Server
Hot-Swap Bays Qty: 2 Bays
Manufacturer Form Factor: Blade
Swappable Drive Form Factor: 2.5″
Swappable Drive Interface: SAS
Dimensions & Weight
Depth: 24.4 in
Height: 2 in
Width: 8 in
Environmental Parameters
Operating Humidity Range: 5 – 93% (non-condensing)
Max Operating Temperature: 95 °F
Min Operating Temperature: 50 °F
Expansion Bays
Form Factor (metric): 6.4 cm SFF
Type: Hot-swap
Expansion Slots
Types: CPU, DIMM 240-pin, Expansion slot, SDHC Card
Hard Drive
Type: No HDD
Networking
Standards: IEEE 802.1p, 802.1Q, 802.3ae
Data Link Protocol: 10 Gigabit Ethernet, FCoE
Ethernet Ports: 4 x 10 Gigabit Ethernet
Processor
Clock Speed: 3 GHz
Installed Qty: 2
Processor Number: E5-2690v2
RAM
Installed Size: 256 GB
Max Supported Size: 384 GB
Slots Qty: 24 DDR3 Slots
Technology: DDR3 SDRAM
