UCS-CX-B200M3-V2 Technical Specifications
Cisco UCS B200 M3 Blade Server
Bay Provided
Form Factor: 2.5″
Free Qty: 2
Total Qty: 2 Bays
Cache Memory
Installed Size: 40 MB
Per Processor Size: 20 MB
Type: L3 cache
Chassis
Form Factor: Blade
Hot-Swap Bays Qty: 2
Manufacturer Form Factor: Blade Server
Server Storage Bays: Hot-swap
Server Swappable Drive Form Factor: 2.5″
Server Swappable Drive Interface: SAS
Dimensions & Weight
Depth: 24.4 in
Height: 2 in
Width: 8 in
Environmental Parameters
Humidity Range Operating: 5 – 93% (non-condensing)
Max Operating Temperature: 95 °F
Min Operating Temperature: 50 °F
Expansion Bays
Form Factor (metric): 6.4 cm
Type: Hot-swap
Expansion Slots
Type: CPU, DIMM 240-pin, Expansion slot
Hard Drive
Type: No HDD
Header
Brand: Cisco
Model: B200 M3 Blade Server (Not a standalone SKU)
Packaged Quantity: 1
Interface Provided
Location: 1 in front
Type: KVM
Mainboard
Chipset Type: Intel C600
Processor Socket: LGA2011 Socket
Miscellaneous
Color Category: Gray
Included Accessories: 2 x CPU Heatsink
Networking
Data Link Protocol: 10 Gigabit Ethernet, FCoE
Ethernet Ports: 4 x 10 Gigabit Ethernet
Processor
Clock Speed: 2.6 GHz
Installed Qty: 2
Max Turbo Speed: 3.4 GHz
Number of Cores: 8-core
Processor Number: E5-2650V2
RAM
Installed Size: 256 GB
Max Supported Size: 384 GB
Slots Qty: 24 DDR3 Slots
Technology: DDR3 SDRAM.
