UCS-EZ-ENTV-B200M3 Technical Specifications
Cisco UCS B200 M3 Value SmartPlay Expansion Pack
Cache Memory
Installed Size: 40 MB
Per Processor Size: 20 MB
Type: L3 cache
Chassis
Form Factor: Blade
Hot-Swap Bays: 2 Bays
Manufacturer Form Factor: Blade Server
Server Storage Bays: Hot swap
Drive Form Factor: 2.5″ (6.4 cm)
Drive Interface: SAS
Dimensions & Weight
Depth: 24.4 in
Height: 2 in
Weight: 9.61 lbs
Width: 8 in
Environmental Parameters
Operating Humidity: 5 – 93% (non-condensing)
Max Operating Temperature: 95 °F
Min Operating Temperature: 50 °F
Expansion Bays
Type: Hot-swap
Expansion Slots
Type: CPU, DIMM 240-pin, Expansion slot
Hard Drive
Type: No HDD
Header
Brand: Cisco
Manufacturer: Cisco Unified Computing
Model: B200 M3 Value SmartPlay Expansion Pack
Packaged Quantity: 1
Product Line: Cisco UCS
Mainboard
Chipset Type: Intel C600
Processor Socket: LGA2011 Socket
Miscellaneous
Color: Gray
Compliant Standards: AS/NZS 60950-1, BSMI CNS 13438 Class A, CISPR 22 Class A, and more.
Included Accessories: 2 x CPU Heatsink
Networking
Compliant Standards: IEEE 802.1p, 802.1Q, 802.3ae, and others.
Data Link Protocol: 10 Gigabit Ethernet, FCoE
Ethernet Ports: 4 x 10 Gigabit Ethernet
Processor
Clock Speed: 2 GHz
Installed Qty: 2
Max Turbo Speed: 2.8 GHz
Cores: 8-core
Processor Number: E5-2650
RAM
Installed Size: 128 GB
Max Supported Size: 384 GB
Memory Speed: 1600 MHz
Slots Qty: 24
