UCS-SP-B200M4-A1T Technical Specifications
Cisco UCS SmartPlay Select B200 M4 Advanced
Bay Provided
Form Factor: 2.5″ SFF
Free Qty: 2
Total Qty: 2 Bays
Cache Memory
Installed Size: 60 MB
Per Processor Size: 30 MB
Chassis
Form Factor: Blade Server
Hot-Swap Bays Qty: 2
Storage Bays: Hot swap
Swappable Drive Form Factor: 2.5″
Dimensions & Weight
Depth: 24.4 in
Height: 2 in
Width: 8 in
Environmental Parameters
Operating Humidity Range: 5 – 93% (non-condensing)
Max Operating Temperature: 95 °F
Min Operating Temperature: 50 °F
Expansion Bays
Form Factor (metric): 6.4 cm SFF
Type: Hot-swap
Hard Drive
Type: No HDD
Processor
Clock Speed: 2.6 GHz
Installed Qty: 2
Manufacturer: Intel
Number of Cores: 12-core
Processor Type: Xeon
RAM
Installed Size: 256 GB
Max Supported Size: 768 GB
Slots Qty: 24 DDR4 Slots
Technology: DDR4 SDRAM
Networking
Ethernet Ports: 4 x 10 Gigabit Ethernet
Remote Management Controller: Cisco Integrated Management Controller
Miscellaneous
Included Accessories: 2 x CPU Heatsink, 2 x drive blanking panels.
