“Image for reference only. Specs are accurate.”
Lenovo Intel Xeon E5-2683 V4 16-Core Processor 2.10 GHz – 00YJ216
Lenovo Intel Xeon E5-2683 V4 16-Core Processor 2.10 GHz. SKU: 00YJ216. Confirm motherboard, firmware and cooling compatibility.
- 16 cores / 32 threads
- 2.1 GHz base frequency
- LGA2011 socket
- 40 MB cache
- 120 W TDP
10,936.60 AED
Description
Xeon E5-2683 v4 overview
00YJ216 identifies the Lenovo Intel Xeon E5-2683 V4 16-Core Processor 2.10 GHz. Its specification includes 16 cores and 32 threads, a 2.1 GHz base frequency and 40 MB cache.
Processor specifications
| Specification | Details |
|---|---|
| Part Number | 00YJ216 |
| Brand | Lenovo |
| Model | E5-2683 v4 |
| Product Type | Server Processor |
| Cores | 16 |
| Threads | 32 |
| Base Clock | 2.10 GHz |
| Socket | LGA2011 |
| L3 Cache | 40 MB |
| Thermal Design Power | 120 W |
| Code Name | Broadwell |
| Manufacturing Process | 14 nm |
| 64-bit Support | Yes |
| Core Stepping | B0 |
| Front Side Bus / QPI | 9.60 GT/s |
| Processor Type | Server |
| Series | Xeon Processor |
| Virtualization Technology Support | Yes |
Compatibility and installation
- Socket and firmware: Check support for Xeon E5-2683 v4 on the target LGA2011 platform. Socket fit alone does not confirm chipset or BIOS support.
- Generation: Keep the v4 suffix in the part request; a similarly numbered processor from another generation should not be treated as an automatic replacement.
- Configuration planning: Check software licensing and the server vendor’s processor-pairing rules before increasing core count or adding a second CPU.
- Cooling: Confirm that the platform and cooling assembly are qualified for the listed 120 W processor TDP.
Package and supply details
| Specification | Details |
|---|---|
| Cooler Included | No |
A cooler is not included in the listed configuration. Confirm the correct cooling assembly for the target system.
Request this part
Provide 00YJ216, the quantity you need and your target system model via the quotation request page, and we will confirm current availability and shipping timeframe.
