100-506095 AMD Radeon Pro W5500 8 GB GDDR6 Graphics Card
100-506095 Overview
The AMD Radeon Pro W550 8GB GDDR6 Pro W550 is a professional workstation GPU designed for CAD, 3D modeling, engineering, architecture, video editing, and visualization workloads. Built on AMD’s 7nm Pro W550, it delivers exceptional performance and power efficiency with 1,408 Pro W550, 8GB of GDDR6 memory, and support for professional software certifications. The 100-506095 is optimized for creators and engineers who require reliable graphics performance for demanding applications.
1,266.00 AED
Description
| Feature | Details |
|---|---|
| Product Name | AMD Radeon Pro W5500 Graphics Card |
| Part Number | 100-506095 |
| GPU | AMD Radeon Pro W5500 |
| Architecture | AMD RDNA (7nm) |
| Stream Processors | 1,408 |
| Compute Units | 22 |
| Graphics Memory | 8GB GDDR6 |
| Memory Interface | 128-bit |
| Memory Bandwidth | 224 GB/s |
| Peak FP32 Performance | 5.35 TFLOPS |
| Interface | PCI Express 4.0 x16 (x8 electrical) |
| Display Outputs | 4 × DisplayPort 1.4 |
| Maximum Resolution | Up to 8K |
| Multi-Display Support | Up to 4 Displays |
| APIs Supported | DirectX 12, OpenGL 4.6, OpenCL 2.0, Vulkan 1.1 |
| Cooling | Active Blower Fan |
| Form Factor | Full Height, Single Slot |
| Power Consumption | 125W |
| Power Connector | 1 × 6-Pin PCIe |
| Board Length | 241 mm (9.5 in) |
| Operating Systems | Windows 11 (64-bit), Linux |
| Professional Software | AMD Software: PRO Edition |
FAQs
1. What is the AMD Radeon Pro W5500 100-506095 designed for?
The AMD Radeon Pro W550 100-506095 is a professional workstation graphics card built for CAD, 3D modeling, architecture, engineering, video editing, and visualization applications.
2. How much memory does the Radeon Pro W5500 include?
It features 8GB of GDDR6 memory with a 128-bit memory interface and 224 GB/s memory bandwidth for handling professional graphics workloads.
3. How many monitors can the 100-506095 support?
The graphics card supports up to four displays simultaneously through four DisplayPort 1.4 connectors and supports resolutions up to 8K.
4. Does the Radeon Pro W5500 support PCI Express 4.0?
Yes. The card uses a PCIe 4.0 x16 interface (operating electrically at x8) for high-speed communication with modern workstation platforms.
5. What power supply is required for this graphics card?
The Radeon Pro W5500 has a typical board power of 125W and requires a single 6-pin PCIe power connector.
6. Is the AMD Radeon Pro W5500 suitable for professional applications?
Yes. It is optimized with AMD Software: PRO Edition drivers and certified for many professional CAD, design, engineering, and content creation applications, ensuring stable and reliable performance.
