20X22AA HP NVIDIA Quadro T1000 4 GB GDDR6 Graphics Card
20X22AA Overview
The 20X22AA HP NVIDIA Quadro T1000 4GB GDDR6 Graphics Card is a compact professional workstation GPU built on the NVIDIA Turing architecture. Designed for CAD, 3D modeling, engineering, GIS, and content creation, it delivers reliable performance with 896 CUDA cores and 4GB of GDDR6 memory. Its low-profile, single-slot design and low 50W power consumption make it an excellent choice for small form factor workstations. Featuring four Mini DisplayPort 1.4 outputs, the HP NVIDIA Quadro T1000 4GB Graphics Card can drive up to four high-resolution displays while supporting professional NVIDIA drivers optimized for leading workstation applications.
1,600.12 AED
Description
| Feature | Specification |
|---|---|
| Model | HP NVIDIA Quadro T1000 |
| Part Number | 20X22AA |
| GPU Architecture | NVIDIA Turing |
| CUDA Cores | 896 |
| Memory | 4GB GDDR6 |
| Memory Interface | 128-bit |
| Memory Bandwidth | 160 GB/s |
| Interface | PCI Express 3.0 x16 |
| Display Outputs | 4 × Mini DisplayPort 1.4 |
| Maximum Displays | Up to 4 |
| Maximum Resolution | 7680 × 4320 (8K) |
| Power Consumption | 50W |
| Cooling | Active Single Fan |
| Form Factor | Low Profile, Single Slot |
| DirectX Support | DirectX 12 |
| OpenGL Support | OpenGL 4.6 |
| Vulkan Support | Vulkan 1.2 |
Frequently Asked Questions
1. What is the 20X22AA HP NVIDIA Quadro T1000 4GB Graphics Card used for?
It is designed for professional applications such as CAD, 3D modeling, engineering, architecture, GIS, and video editing where stability and certified drivers are essential.
2. Does the Quadro T1000 support multiple monitors?
Yes. It features four Mini DisplayPort 1.4 outputs and can drive up to four high-resolution displays simultaneously.
3. Is an external power connector required?
No. The card has a maximum power consumption of 50W and is powered directly through the PCIe slot.
4. Can this graphics card fit into small form factor workstations?
Yes. Its low-profile, single-slot design makes it suitable for compact business and professional workstation systems.
5. Is the HP Quadro T1000 suitable for gaming?
While it can run many games, it is optimized for professional workloads with certified drivers rather than gaming performance.
6. Which professional software is supported?
The card is certified for many industry-standard applications, including AutoCAD, SOLIDWORKS, Autodesk Revit, Autodesk Maya, Adobe Creative Cloud, and other professional visualization software.
