669256-B21 HP Proliant DL380e G8 CTO Chassis – No CPU

669256-B21 Technical Specifications

HP Proliant DL380e G8 CTO Chassis – No CPU, No RAM

GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 669256-B21
Product Name: Proliant DL380e Gen8 2U Rack Mount CTO
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon
Supported Sockets: 2 x HP Smart Socket LGA1356
64-Bit Computing: Yes
Installed Quantity: None
Maximum Supported Quantity: 2
Upgradability: Upgradable
Chipset Type: Intel C600
MEMORY:
Installed Size: None
Maximum Capacity: 384 GB
Memory Technology: DDR3 SDRAM
Form Factor: DIMM 240-Pin
Total Memory Slots: 12 DDR3 Slots
STORAGE & STORAGE CONTROLLER:
Hard Drive: None, supports up to 25 SFF drives
Storage Controller Type: 1 x RAID – Plug-In Card – PCI Express 3.0 x8
Controller Interface: Serial SATA-300 / SAS 2.0
Storage Controller Name: HP Dynamic Smart Array B120i with Zero Memory
CARD READER:
Card Reader Type: Integrated Card Reader
Supported Flash Memory Cards: SD Memory Card
DISPLAY & GRAPHICS CONTROLLERS:
Graphics Controller Type: Integrated
Graphics Processor: Matrox G200
NETWORK & COMMUNICATION:
Networking: Network Adapter – PCI Express 2.0 x2 – Integrated
Ethernet Ports: 4 x Gigabit Ethernet
Ethernet Controller(s): HP Ethernet 1GB 4-Port 366i Adapter
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller: Integrated Lights-Out 4
Features: Wake On LAN (WOL), PXE Support
POWER DEVICE:
Device Type: Power Supply – Hot-Plug
Power Redundancy: Optional
Redundancy Scheme: 1+1 (with optional power supply)
Installed Quantity: 0
Maximum Supported Quantity: 2
Voltage Required: AC 120/230 V (50/60 Hz)
