779559-S01 HP Proliant DL380 G9 – 1x Intel Xeon E5-2620v3 2.4GHz Server

779559-S01 Technical Specifications

HP Proliant DL380 G9 – 1x Intel Xeon E5-2620v3 2.4GHz Server

GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 779559-S01
Product Name: Proliant DL380 Gen9 2U Rack Mount (S-Buy)
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5-2620v3 at 2.4GHz
Multi-Core Technology: Hexa-Core (6 cores)
Installed Quantity: 1
Maximum Supported Quantity: 2
Upgradability: Yes
64-Bit Computing: Supported
Chipset Model: Intel C610
CACHE MEMORY:
Installed Size: L3 Cache – 15 MB
Cache Per Processor: 15 MB
RAM:
Installed Size: 16GB
Maximum Supported Size: 384GB
RAM Technology: DDR4 SDRAM
Memory Speed: 1866 MHz
Form Factor: DIMM 288-Pin
Memory Slots: 24 x DDR4 RAM Slots
Features: Registered, HP SmartMemory
STORAGE & CONTROLLER:
Hard Drive: None
Type: 1x RAID – Plug-In Card – PCI Express 3.0 x8
Controller Interface Type: SATA 6Gb/SAS 3.0
Storage Controller Name: HP Smart Array P840 with 4GB FBWC
Channel Quantity: 16
RAID Levels: 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM
Buffer Size: 4GB
NETWORKING:
Ethernet Ports: 4x Gigabit Ethernet
Ethernet Controller: HP 331FLR
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller: Integrated Lights-Out 4
Features: Wake On LAN (WOL), PXE Support.
