“Image for reference only. Specs are accurate.”
9105-22A-EN1B IBM PCIe3 Low Profile 32GB Dual Port Fiber Channel Adapter
9105-22A-EN1B Overview
The 9105-22A-EN1B IBM PCIe3 Low Profile 32GB Dual Port Fiber Channel Adapter is a high-performance Fibre Channel host bus adapter designed for IBM Power Systems and enterprise storage area network environments. Based on the Emulex LPe32000-series HBA, it provides two independent 32Gb Fibre Channel ports through SFP+ interfaces with included SR optical transceivers. The PCIe Gen3 x8 interface can operate in either x8 or x16 PCIe slots, while automatic speed negotiation supports 8Gbps, 16Gbps, and 32Gbps connectivity. Its short, low-profile form factor makes it suitable for space-constrained server configurations, while dual-port connectivity supports high-bandwidth SAN access, storage virtualization, and redundant Fibre Channel deployments.
Description
| Specification | Details |
|---|---|
| Brand | IBM |
| Part / Feature | 9105-22A-EN1B |
| Feature Code | EN1B |
| Adapter FRU Number | 01FT704 |
| Product Type | Fibre Channel Host Bus Adapter (HBA) |
| Bus Interface | PCI Express 3.0 x8 |
| Form Factor | Short, Low-Profile |
| Fibre Channel Ports | 2 × Fibre Channel |
| Maximum Port Speed | 32Gbps per port |
| Supported Link Speeds | 8Gbps / 16Gbps / 32Gbps |
| Port Connector | SFP+ |
| Optics | SR Optical Transceivers Included |
| Fiber Type | Multimode Fiber |
| HBA Controller | Emulex LPe32000-Series Based |
| PCIe Slot Support | x8 or x16 PCIe Slot |
| Voltage | 3.3V / 12V |
| Fibre Channel Mode | Single Initiator and NPIV Multiple Initiator Support |
| Primary Application | Enterprise SAN and Storage Connectivity |
| Compatible Platform | Selected IBM Power Systems |
| Management | Enhanced Diagnostics and Manageability |
Frequently Asked Questions
1. What is the maximum speed of the 9105-22A-EN1B Fibre Channel adapter?
It supports Fibre Channel speeds of up to 32Gbps per port and can automatically negotiate between 8Gbps, 16Gbps, and 32Gbps depending on the connected SAN infrastructure.
2. How many Fibre Channel ports does this IBM adapter provide?
The adapter provides two independent Fibre Channel ports, with each port capable of delivering up to 32Gbps Fibre Channel connectivity.
3. Is the EN1B adapter low profile?
Yes. IBM specifies EN1B as the low-profile version of the EN1A/EN1B adapter family, with a short low-profile form factor designed for compatible PCIe server slots.
4. What type of optical connectivity does this Fibre Channel adapter use?
It uses two SFP+ Fibre Channel ports with SR optical transceivers and is designed for multimode fiber connectivity.
5. What is the IBM adapter FRU number for EN1B?
The IBM adapter FRU number is 01FT704. IBM lists EN1B as feature code EN1B under the PCIe3 x8 dual-port 32Gb Fibre Channel adapter family.
