C1109-2PLTEGB Cisco 1100 Series ISR – Integrated Services Router
C1109-2PLTEGB Overview
The Cisco 1100 Series Integrated Services Router (ISR) offers robust Cisco IOS® XE Software, enabling WAN connectivity, extensive security, and both wired and wireless access within a single high-performance device. Perfectly suited for small to medium enterprise branch offices, the C1109-2PLTEGB model is an LTE-enabled router designed for efficiency and reliability.
Description
C1109-2PLTEGB Technical Specifications
Cisco 1100 Series Integrated Services Router
Description: The C1109-2PLTEGB is a Cisco ISR1109-2P router featuring LTE and GB capabilities.
WAN GE: 1
WAN GE/SFP combo: Not Applicable
ADSL2/VDSL2+: Not Applicable
LTE Advanced (CAT6): Not Applicable
802.11ac: Not Applicable
LAN GEL: 2
PoE or PoE+: Not Applicable
Integrated USB 3.0 AUX/console: Yes (No AUX)
Pluggable: Not Applicable. It utilizes the same CAT4 technology as the PLTE-GB model.
Dimensions (H x W x D)
1.15 x 7.6 x 6.3 inches (29.2 x 193.0 x 160.0mm) including rubber feet.
AC Power Input Voltage
Universal 100 to 240 VAC
Frequency
50-60 Hz
Maximum output power: 30W (default)
Output voltages: 12 VDC
Console Port: Micro USB console (USB 3.0)
Default and maximum DRAM: 4GB
Default and maximum flash: 4GB
Approvals and Compliance: Emission standards include 47 CFR Part 15, CISPR 32 Edition 2, and several IEC and UL standards for safety and performance.
