DWDM-SFP-5979 Cisco 1000BASE-DWDM SFP Transceiver Module

DWDM-SFP-5979 Technical Specifications

Cisco 1000BASE-DWDM SFP Transceiver

Features
This transceiver is functionally equivalent to the Cisco DWDM-SFP-5979 model. It supports data rates of up to 1.25Gb/s, making it ideal for high-performance networking. The device operates over a distance of up to 80km using 9/125µm G.652D single-mode fiber. It adheres to a 100GHz ITU Grid in the C Band and incorporates Digital Optical Monitoring (DOM) for improved diagnostics and troubleshooting. This transceiver is compatible with DWDM MUX/DEMUX systems, enabling a cost-effective fiber solution for 1000BASE applications.
Specifications

• Form Factor: DWDM SFP
• Data Rate: 1.25 Gb/s
• Wavelength: CH22 – 1559.79nm
• Fiber Type: SMF
• Max Distance: 80 km
• Optical Components: DWDM DFB/PIN
• Transmitter Power: 0 ~ 5 dBm
• Extinction Ratio: > 9 dB
• Receiver Sensitivity: < -26 dBm
• Receiver Overload: > 0 dBm
• Connector: Duplex LC
• Digital Diagnostic Monitoring: Yes

Environment Operating:
Operating temperature ranges from 0°C to 70°C, while storage conditions are between -40°C to 85°C. The weight of the transceiver is 0.025 kg. It is suitable for C Band DWDM networks, fiber channel over DWDM, and Gigabit Ethernet over DWDM. Compliance with IEC/EN 61000-4-2, IEC-60825, and FDA 21CFR 1040.10 and 1040.11 standards ensures its quality and safety. RoHS compliant.
