“Image for reference only. Specs are accurate.”
EAP772-OUTDOOR TP-Link Omada Tri Band Wi-Fi 7 Access Point
EAP772-OUTDOOR Overview
The EAP772-OUTDOOR TP-Link Omada Tri-Band Wi-Fi 7 Access Point is a high-performance outdoor wireless solution built for fast, reliable connectivity across demanding business and outdoor environments. It delivers up to 11Gbps combined wireless throughput across 2.4GHz, 5GHz, and 6GHz bands, with six spatial streams, 320MHz channels, 4K-QAM, and Multi-Link Operation (MLO). Its IP68-rated weatherproof enclosure provides protection against dust and water, while the 2.5GbE PoE+ port enables high-speed wired backhaul. With up to 300m² recommended omnidirectional coverage, Omada Mesh, seamless roaming, and centralized management, it is well suited for hotels, business parks, farms, yards, parking areas, and other outdoor networks.
862.42 AED
Description
| Specification | Details |
|---|---|
| Brand | TP-Link |
| Product Series | Omada |
| Model | EAP772-Outdoor |
| Product Type | Outdoor Wi-Fi 7 Access Point |
| Wireless Standard | IEEE 802.11be/ax/ac/n/g/b/a |
| Wireless Bands | 2.4GHz / 5GHz / 6GHz |
| Wireless Speed | Up to 11Gbps (US) / 9.3Gbps (EU) |
| Spatial Streams | 6-Stream |
| 2.4GHz Speed | Up to 688Mbps |
| 5GHz Speed | Up to 4,324Mbps |
| 6GHz Speed | Up to 5,765Mbps |
| Channel Width | Up to 320MHz |
| Antennas | 2 × 4dBi (2.4GHz), 2 × 6dBi (5GHz), 2 × 6dBi (6GHz) |
| Coverage | Up to 300m² (3,200ft²) Recommended Omnidirectional Coverage |
| Ethernet Port | 1 × 2.5GbE RJ-45 |
| Power Supply | 802.3at PoE+ |
| Maximum Power Consumption | 21.5W |
| Weatherproof Rating | IP68 |
| Bluetooth | BLE 5.2 |
| Wireless Technologies | 4K-QAM, MLO, OFDMA, MU-MIMO, Beamforming, Multi-RU |
| Mesh Support | Omada Mesh |
| Roaming | Seamless Roaming (802.11k/v/r) |
| Concurrent Clients | 380+ |
| Management | Omada App, Cloud-Based, Hardware & Software Controller |
| Mounting | Wall / Pole Mounting |
| Operating Temperature | -30°C to 70°C |
| Dimensions | 230 × 207.5 × 69.7mm |
Frequently Asked Questions
1. What is the EAP772-OUTDOOR designed for?
The EAP772-OUTDOOR is designed for high-performance outdoor Wi-Fi 7 networking in locations such as hotels, business parks, farms, yards, parking areas, and commercial outdoor spaces.
2. What wireless speeds does this TP-Link Omada access point support?
The access point provides up to 11Gbps combined wireless throughput in supported US configurations across the 2.4GHz, 5GHz, and 6GHz bands. EU configurations are rated up to 9.3Gbps.
3. Is the EAP772-OUTDOOR weatherproof?
Yes. It features an IP68-rated enclosure designed to provide strong protection against dust and water, along with an operating temperature range of -30°C to 70°C for demanding outdoor installations.
4. Does this outdoor Wi-Fi 7 AP support 6GHz Wi-Fi?
Yes. The access point supports the 6GHz band and can use AFC to enable supported outdoor 6GHz operation. Availability of AFC and 6GHz outdoor use depends on regional regulations.
5. Can the TP-Link Omada EAP772-OUTDOOR be managed centrally?
Yes. It supports centralized management through the Omada Cloud-Based Controller, Omada Hardware Controllers, Software Controller, and Omada App. It also supports features such as Omada Mesh, seamless roaming, VLAN management, captive portal, and access control.
