FTLF1319F1xTL Finisar 2Gbps RoHS Compliant SFF Transceiver
FTLF1319F1xTL Overview
The Finisar FTLF1319F1xTL Small Form Factor (SFF) transceivers are designed to meet the 2×5 standard package outlined by the Small Form Factor Multi-Sourcing Agreement (MSA). They support Gigabit Ethernet as defined in IEEE Draft P802.3z/D5.02 and are also compatible with Fibre Channel standards including FC-PH, PH2, PH3, and FC-PI-2 10.04.
Description
FTLF1319F1xTL Technical Specifications
Finisar 2 Gigabit RoHS Compliant Long Wavelength
The FTLF1319F1xTL transceiver supports bi-directional data links at speeds of up to 2.125Gb/s, making it ideal for Fast Ethernet applications. It features a standard 2×5 pin SFF footprint and utilizes a 1310nm Fabry-Perot laser transmitter. This model includes an LC Duplex connector and ensures very low jitter performance. With a reach of up to 10 km on 9/125μm single-mode fiber, it is housed in a metal enclosure to minimize EMI. The device operates on a single 3.3V power supply and boasts low power consumption of less than 700mW. Additionally, it is designed for industrial-grade performance, operating within a temperature range of -40°C to 85°C.
