FTLX6624MCC TX/RX Optical Fiber 11.35Gbps 30-Pin XFP Transceiver
FTLX6624MCC Overview
The FTLX6624MCC-xx is a compact 10Gb/s (XFP) transceiver that adheres to the XFP Multi-Source Agreement (MSA) Specification. It is designed to support amplified DWDM 10Gb/s SONET/SDH, 10 Gigabit Ethernet, and 10 Gigabit Fibre Channel applications over a distance of 40km without the need for dispersion compensation.
5,229.75 AED
Description
FTLX6624MCC Technical Specifications
TX/RX Optical Fiber 11.35Gbps 30-Pin XFP
The FTLX6624MCC transceiver operates at a data rate of 11.35 Gbps, suitable for 10 Gigabit Ethernet applications. Key specifications include:
– **Maximum Fall Time:** 0.04 ns
– **Mounting Type:** Snap Fit To Panel Mount
– **Operating Voltage Range:** 3.1300 to 5.2500 V
– **Temperature Range:** -5 to 70 °C
– **Pin Count:** 30
– **Dimensions:** 78 x 18.35 x 8.5 mm
– **Screening Level:** Commercial
– **Fiber Mode:** Single Mode Fiber (SMF)
– **Peak Wavelength (nm):** 1563.86(Max)/1615(Max)
– **Form Factor:** XFP
This transceiver is engineered for high-performance applications, ensuring reliable connectivity over long distances.
