GPSD-7-27-24-58 Panorama Antennas MiMo 2G/3G/4G + GPS/GNSS Antenna Whip Mounting
GPSD-7-27-24-58 Overview
The GPSD-7-27-24-58 Panorama Antennas MiMo Sharkee™ 2G/3G/4G + GPS/GNSS Antenna with Whip Mounting & Optional MiMo WiFi is a rugged, multifunction vehicle antenna designed for fleet management, public safety, transportation, industrial, and IoT applications. Its compact OEM-style SharkFin housing integrates 2×2 MiMo cellular antennas, an active GPS/GNSS antenna, and an external whip mount for VHF, UHF, or 700/800MHz radios. Optional 2×2 MiMo WiFi support further enhances wireless connectivity, making it a versatile all-in-one antenna solution.
562.28 AED
Description
| Specification | Details |
|---|---|
| Brand | Panorama Antennas |
| Part Number | GPSD-7-27-24-58 |
| Product Type | Multifunction Vehicle Antenna |
| Cellular Support | 2G / 3G / 4G LTE |
| Cellular MiMo | 2×2 MiMo |
| GPS Frequency | 1562–1612 MHz |
| GNSS Support | GPS, GLONASS, Galileo, BeiDou |
| GPS LNA Gain | 26 dB |
| LTE Frequency Range | 698–960 MHz, 1710–3800 MHz |
| Optional WiFi | 2×2 MiMo, 2.4 GHz & 5 GHz |
| Radiation Pattern | Omnidirectional |
| Mounting Type | Panel Mount |
| Whip Mount | M6 × 0.75 |
| Enclosure Rating | IP66 |
| Color | Black |
| Dimensions | 170 × 60 × 50 mm |
| Connector Type | SMA (configuration dependent) |
Frequently Asked Questions (FAQs)
1. What wireless technologies does this GPSD-7-27-24-58 antenna support?
It supports 2G, 3G, 4G LTE, GPS/GNSS, and optional 2×2 MiMo WiFi connectivity in a single compact housing.
2. Which satellite navigation systems are supported?
The antenna supports GPS, GLONASS, Galileo, and BeiDou for accurate positioning and navigation.
3. Is this antenna suitable for vehicle installations?
Yes. Its low-profile SharkFin design and single-hole mounting make it ideal for commercial, fleet, emergency, and industrial vehicles.
4. Does it support external radio antennas?
Yes. It includes an integrated M6 whip mount for connecting compatible VHF, UHF, or 700/800MHz whip antennas.
5. Can the antenna withstand outdoor environments?
Yes. The IP66-rated enclosure provides excellent protection against dust and water, making it suitable for harsh outdoor conditions.
6. Is WiFi included with this model?
This version supports optional 2×2 MiMo WiFi functionality depending on the selected configuration and cable option.
