JD099B HPE X120 1Gbps 1000Base-LX-BX10-D SFP Module
JD099B Overview
The JD099B HPE X120 1Gbps 1000Base-LX-BX10-D SFP Module is a hot-pluggable Gigabit Ethernet transceiver engineered for reliable long-distance fiber connectivity over a single strand of single-mode fiber. Designed for enterprise, campus, and service provider networks, this compact SFP module supports 1000BASE-BX10-D technology, transmitting at 1490nm and receiving at 1310nm with a maximum transmission distance of 10 kilometers. The JD099B HPE X120 1Gbps 1000Base-LX-BX10-D SFP Module helps reduce fiber infrastructure costs by enabling bidirectional communication over one fiber strand while delivering stable, high-speed network performance.
5,130.66 AED
Description
| Specification | Details |
|---|---|
| Product Number | JD099B |
| Product Type | SFP Optical Transceiver |
| Brand | HPE |
| Series | X120 |
| Form Factor | SFP (Mini-GBIC) |
| Ethernet Standard | 1000BASE-BX10-D |
| Data Rate | 1 Gbps |
| Fiber Type | Single-Mode Fiber (SMF) |
| Connector | LC Simplex |
| Maximum Distance | 10 km |
| Transmit Wavelength | 1490 nm |
| Receive Wavelength | 1310 nm |
| Duplex Mode | Full Duplex |
| Standard | IEEE 802.3ah |
| Installation | Hot-Pluggable |
Frequently Asked Questions (FAQs)
Q1. What is the JD099B HPE X120 1Gbps 1000Base-LX-BX10-D SFP Module used for?
It is a Gigabit Ethernet optical transceiver designed to provide 1Gbps network connectivity over a single strand of single-mode fiber for distances up to 10 kilometers.
Q2. What fiber type does this module support?
The module is designed for single-mode fiber (SMF) and uses an LC simplex connector for bidirectional optical communication.
Q3. What is the maximum transmission distance?
The transceiver supports optical communication over distances of up to 10 km when deployed with the appropriate BX10-U counterpart module and compatible single-mode fiber.
Q4. Does this module require a matching transceiver?
Yes. Since it is a BX10-D bidirectional transceiver, it must be paired with a compatible BX10-U module that uses complementary transmit and receive wavelengths.
Q5. Is the module hot-swappable?
Yes. It supports hot-swappable installation, allowing administrators to install or replace the module without powering down compatible networking equipment.
Q6. Which wavelengths does the module use?
The module transmits at 1490nm and receives at 1310nm, enabling bidirectional communication over a single optical fiber.
