MZ7LH480 SAMSUNG PM883 480GB SATA 6Gbps SSD

MZ7LH480 Technical Specifications

SAMSUNG PM883 Series 480GB SATA 6Gbps 2.5-inch Enterprise Internal Solid State Drive

Main Specifications:

Product Description: The Samsung PM883 Series MZ7LH480 is a high-performance Solid State Drive (SSD) with a capacity of 480GB and a SATA 6Gb/s interface.
Type: Internal Solid State Drive
Capacity: 480GB
Hardware Encryption: Yes
Encryption Algorithm: AES 256-bit
NAND Flash Memory Type: 3D Triple-Level Cell (TLC)
Form Factor: 2.5-inch
Interface: SATA 6Gb/s
Data Transfer Rate: Up to 600 Mbps
Features: Native Command Queuing (NCQ), TRIM support, Power Disable Pin (Pin3)
Dimensions (W x D x H): 2.7 in x 3.9 in x 0.3 in
Weight: 2.47 oz

Extended Specifications:
Device Type: Internal Solid State Drive
Capacity: 480GB
Hardware Encryption: Yes
Encryption Algorithm: 256-bit AES
NAND Flash Memory Type: 3D TLC
Form Factor: 2.5-inch
Bytes Per Sector: 512
Features: NCQ, TRIM support, Power Disable Pin (Pin3)
Width: 2.7 in
Depth: 3.9 in
Height: 0.3 in
Weight: 2.47 oz

Performance:
Drive Writes Per Day (DWPD): 1.3
SSD Endurance: 683TB
Data Transfer Rate Details (Serial ATA): 600 Mb/s
Drive Transfer Rate: 600 Mbps (external)
Internal Data Rate: 550 Mbps (read) / 520 Mbps (write)
4KB Random Read: 98,000 IOPS
4KB Random Write: 28,000 IOPS
Average Latency: 40 µs
