UCSC-C3X60-SVRN7 Cisco Systems C3X60 Server Node E5-FD

UCSC-C3X60-SVRN7 Technical Specifications

Cisco Systems C3X60 Server Node E5-FD

General Information
The Cisco C3X60 Server Node E5-FD is identified by the manufacturer part number UCSC-C3X60-SVRN7. This server is classified as a part of the Cisco UCS product line.
Controllers
It includes a 12Gb/s SAS controller, supporting various RAID levels such as 0, 1, 5, 6, 10, 50, and 60.
Memory
Equipped with a standard memory of 256 GB, the server can be expanded to a maximum of 512 GB using DDR3 SDRAM technology.
Network & Communication
The server supports Gigabit Ethernet technology for high-speed connectivity.
Power Description
It operates on input voltages of 120 V AC and 230 V AC, with four installed power supplies, each capable of delivering a maximum power supply wattage of 1050 W.
Processor & Chipset
This server supports up to two processors, both installed, featuring Intel Xeon technology. The processor model is E5-2695v2, which boasts a dodeca-core architecture with a speed of 2.40 GHz.
Physical Characteristics
Designed for rack mounting, it has a 4U form factor, with dimensions of 6.9″ in height, 17.5″ in width, and 32″ in depth.
