WMS-EZ-C220-250P Technical Specifications
Cisco UCS C220 M3 High-Density Rack Server
Bay Configuration
Form Factor: 3.5″
Total Bays: 8 (Hot-swap)
Cache Memory
Installed Size: 30 MB (15 MB per processor)
Type: L3 cache
Chassis
Rack-mountable with 8 hot-swap bays
Drive Interface: SAS
Dimensions & Weight
Depth: 28.5 in
Height: 1.7 in
Width: 16.9 in
Weight: 22.05 lbs
Environmental Parameters
Operating Humidity: 10 – 90% (non-condensing)
Operating Temperature: 32 °F to 104 °F
Expansion Slots
Type: PCIe 2.0 (x8 and x16)
Hard Drive
Installed Qty: 4 (Hot-swap, 7200 rpm)
Networking
Ethernet: 2 x Gigabit Ethernet, integrated Intel I350
Power Supply
Max Supported Qty: 2, 650 Watt with redundancy
Included Accessories
2 x CPU Heatsink, Rack rail kit
Miscellaneous
Color: Gray, compliant with various standards including UL and FCC.
