“Image for reference only. Specs are accurate.”
C1111-4PWB Cisco 1100 Series ISRs – 4 Port Router
C1111-4PWB Overview
The Cisco 1100 Series Integrated Services Router (ISR) combines Cisco IOS® XE Software, offering robust WAN capabilities, comprehensive security, and both wired and wireless access in a high-performance solution. Perfectly suited for small to medium-sized enterprise branch offices, the C1111-4PWB features four ports, Dual GE WAN, and 802.11ac -B WiFi connectivity.
4,290.23 AED
Description
C1111-4PWB Technical Specifications
Cisco 1100 Series Integrated Services Router
Description
The ISR 1100 is a versatile Dual GE WAN router equipped with 802.11ac -B WiFi capabilities.
Physical Properties
Dimensions (H x W x D):
Non-LTE models:
H x W x D = 1.75 x 12.7 x 9.03 in. (42 x 323 x 230mm) with rubber feet included.
Weight with AC Power Supply (without modules):
Maximum of 5.5 lbs. (2.5 kg).
AC Input Power
Input voltage:
Universal 100 to 240 VAC.
Frequency:
50-60 Hz.
Input current:
Maximum 0.82A when PoE is not enabled; 1.55A when PoE is enabled.
Surge current:
Peaks at 90 A and less than 8 Arms per half cycle.
Ports
Includes:
Micro USB Port, one RJ-45 for console access, and a USB port.
USB 3.0 Type A host port
Supports USB flash memory devices.
Console management via a 5-pin micro Type B USB port.
10/100/1000 Gigabit Ethernet:
Two GE ports available, one combo port (10/100/1000 RJ-45 or SFP) labeled GE0/0/0 and one dedicated RJ-45 port labeled GE0/0/1.
Wireless VLANs
Supports up to 32 VLANs, both encrypted and non-encrypted.
Wireless specifications include 2×2 .11ac Wave 2.
Default and maximum DRAM is 4GB, with the same for flash storage.
Inline PoE
Features 4 ports for -8P PIDs and 2 ports for -4P PIDs, compliant with 802.3af and 802.3at PoE+ standards.
Acoustic specifications indicate a fanless design for the Cisco 1100 Series ISRs.
