EX-SFP-1GE-SX – Juniper 1000BASE-SX SFP Transceiver Module
Juniper EX-SFP-1GE-SX
Introducing the STARTECH.COM Gigabit Fiber 1000BASE-SX SFP Transceiver Module, a fully compatible solution for Juniper devices. This high-performance module features a multi-mode LC connector, supporting distances up to 550 meters (1804 feet) for seamless connectivity in Gigabit Ethernet applications.
1,005.58 AED
Description
EX-SFP-1GE-SX Technical Specifications
Juniper 1000BASE SX SFP Module
This SFP (Mini-GBIC) transceiver module is designed for plug-in use, providing reliable wired connectivity. The 1000BASE-SX cabling type enables Gigabit Ethernet data link protocol, achieving data transfer rates of up to 1 Gbps.
Key features include:
- Vendor: FS
- Form Factor: SFP
- Maximum Data Rate: 1.25 Gbps
- Wavelength: 850 nm
- Maximum Cable Distance: 550m (50/125µm OM2 MMF), 275m (62.5/125µm OM1 MMF), 220m (62.5/125µm FDDI MMF)
- Connector: Duplex LC
- Media Type: MMF
- Transmitter Type: VCSEL
- Receiver Type: PIN
- DDM/DOM: Supported
- Operating Temperature Range: 0 to 70°C (23 to 158°F)
- TX Power: -9.5 to -3 dBm
- Receiver Sensitivity: < -17 dBm
- Power Consumption: ≤ 0.8 W
- Receiver Overload: -3 dBm
- Bit Error Ratio (BER): 1E-12
- Extinction Ratio: > 9 dB
- EMC (Electromagnetic Compatibility): Supported
- MTBF (SX): 2,457,002 Hours
